RST II mid-bass driver design | 1" C-CAM Gold Dome tweeter | 8" C-CAM mid-bass driver | Compact and bookshelf-friendly | Rear-ported | HiVe II port system | Perfect for smaller stereo music set-ups | Wide range of high-quality finishes.
Specifications
System Format: 2 - way
Frequency Response, In-Room (-6dB): 35 Hz - 35 kHz
Sensitivity (2.83v @ 1m): 87.5 dB
Nominal Impedance: 8 Ohms
Minimum Impedance: 4.9 Ohm @ 170 Hz
Maximum SPL (single, free-field): 106 dB
Power Handling (RMS): 120 W
Recommended Amplifier Requirements: 40 - 120 W
Crossover Frequency: 2.3 kHz
Port Tuning Frequency: 42 Hz
Bass Alignment: Bass reflex
HiVe II port system
Drive Unit Complement
1 x 8" C-CAM RST II mid-bass driver
1 x 1" (25 mm) C-CAM Gold Dome tweeter with UD Waveguide II
External Dimensions (Including Grille and Terminals (H x W x D)): 375 x 230 x 332 mm (143/4 x 91/16 x 135/64")
External Dimensions (including Outrigger Feet and Spikes (H x W x D)): N/A
Weight: 9.4 kg (20 lb 12 oz)
