And it’s intelligent, too, with features like Automatic Position Correction that learns the layout of the room and automatically corrects the acoustics of the music you hear. As a result, you can put your subwoofer wherever you like, with no restrictions, and still enjoy amazingly lifelike sound.
Specifications
Lower Frequency Limit
20 Hz (Typical IEC room)
Upper Frequency Limit
40 – 120 Hz variable
Low Pass Filter Alignment
Active 4th order 24 db/octave
Amplifier Output
500 W continuous
Amplifier Classification
Class-D amplifier with switched-mode power supply (SMPSU)
Bass EQ Profiles
1: Movie
2: Music
3: Impact
Phase Control
0 & 180 degrees
Auto Sensing
Line Level >2 mV
Input Level Requirements
Standby after 20 minutes if no signal sensed
Drive Unit Complement
1 x 12" C-CAM subwoofer driver featuring triple suspension and 3" long throw voice coil
Trigger Input
5 – 12 V via 3.5 mm mono mini-jack socket
Cabinet Dimensions (Excluding Grille and Terminals (H x W x D))
340 x 340 x 380 mm (133/8" x 133/8" x 1415/16”)
Dimensions (Including Grille, Amp and Feet)
370 x 340 x 410 mm (149/16" x 133/8" x 161/8”)
Mains Input Voltage
110 – 120 Vac /
220 – 240 Vac 50/60 Hz (Electronically Auto selected)
Power Consumption
400 W / 0.5 W in Standby (ErP approved)
Weight (unpacked)
20.1 kg (44 lb 5 oz)
