Connectivity is comprehensive: HDMI ARC/eARC ensures seamless TV integration, while optical, RCA, and 3.5mm inputs handle other sources. High-resolution wireless streaming is effortless via DTS Play-Fi (192kHz/24-bit), Apple AirPlay 2, Chromecast built-in, and Bluetooth 5.0 with aptX. A dedicated subwoofer output allows for enhanced bass.
Control is intuitive with the SVS Play-Fi app, an IR remote, or the front-panel OLED display and physical controls (including 6 custom presets). With a frequency response of 42 Hz - 25 kHz (±3 dB) and elegant finishes, these compact speakers (11.6 inches H×7.1 inches W×9.0 inches D) deliver immersive, audiophile-grade performance without the clutter of separate components.
Features
True 2-Channel Audio for Convincing and Immersive Stereo Sound
Left/Right powered speaker setup delivers true stereo sound with punchy dynamics, massive soundstage, and pinpoint imaging.
High-Resolution Audio over WiFi enables lossless streaming for the most discerning audiophiles.
200 Watt (50 Watts x 4) Amplifier for Massive Dynamic Output
Potent Class-D amplifier delivers 50-watts to each woofer and tweeter for effortless power and room-energizing slam and impact with revealing clarity. Plays crystal clear even at high volumes with output that far exceeds the cabinet size.
Digital Electronic Crossover for Refined and Dynamic Sound
Maximizes performance of each driver by controlling power delivery and frequency response with absolute precision. The result is pinpoint transient speed and massive dynamic output that belies the compact cabinet size.
Acoustically Optimized 1” Aluminum Dome Tweeter
Renders crystal clear highs with lifelike realism, the tweeter’s airy presentation reveals every sonic detail with pristine clarity and pinpoint accuracy. An FEA-optimized diffuser ensures broad dispersion for a wide and convincing soundstage.
High-Output 5.25” Mid-Bass Driver
The majority of audio content in music and movies is present in the mid and low frequencies so it’s imperative to have a driver capable of producing slam and impact with refinement. Lightweight yet stiff driver materials in the mid-bass driver deliver effortless and unveiling sound with flawless tonal accuracy and chest-thumping bass.
192kHz/24-Bit DAC for High-Resolution Streaming over WiFi
Sophisticated digital to analog convertor renders highest quality playback from all streaming services and connected devices.
Versatile Connectivity
- HDMI input with ARC/eARC for High-Resolution stereo sound from your TV
- Line level, optical, 3.5mm AUX, and ethernet inputs for connecting to a wide range of devices
- Subwoofer output for deeper, heart-pounding bass
Smart and Seamless Control
- Native control via Apple Airplay 2 for iPhone and iOS, Spotify Connect, & Chromecast for Android phones and Devices
- Smartphone, tablet, or PC control with the DTS Play-Fi app
- Data-rich front panel user interface
- IR Remote
- Alexa, Siri, Hey Google voice commands via supported devices
- 6 custom presets for instant access to playlists, streaming music services, and more with touch of a button
- Multi-room/Whole Home Audio compatible with all DTS Play-Fi enabled products
Specifications
Frequency Response / Acoustic Data: - Frequency Response: 42Hz – 25kHz (±3 dB) Active Speaker Cabinet Dimensions: - 295mm (H) X 180mm (W) X 228mm (D) - 11.61" (H) X 7.09" (W) X 8.96" (D) Passive Speaker Cabinet Dimensions: - 295mm (H) X 180mm (W) X 225mm (D) - 11.61" (H) X 7.09" (W) X 8.85" (D) Package Dimensions: - 390mm (H) X 465mm (W) X 296mm (D) - 15.35" (H) X 18.31" (W) X 11.73" (D) Weight: - Active Speaker Weight Unboxed: 12.3 lbs (5.58kg) - Passive Speaker Weight Unboxed: 11.68 lbs (5.3kg) - Packaged Weight System Pack: 28.0 lbs (12.7kg)
Driver Specs: 1” Aluminum Dome Tweeter: - FEA-optimized diffuser for airy and unveiled presentation - Aluminum dome for exceptional transient response 5.25" Mid-bass Driver: - Polypropylene cone for excellent stiffness/mass ratio and pistonic behavior - Aluminum shorting ring to reduce gap inductance, lower distortion, and enhance high frequency response - Cast ABS-fiberglass composite basket ensures precision component alignment and excellent thermal transfer - Vented voice coil former minimizes air compression artifacts
Amplifier Specs: - Dual Class-D Power Amps for Discrete Driver Bi-amplification - 200 watt (50 watt x 4) RMS Power - Digital controlled tweeter-to-woofer crossover: 2kHz (12dB/octave slope) Speaker Cabinet Specs: Finish Options: Piano Gloss Black and Piano Gloss White - 2.36" wide-flared rear-firing port - Protective cloth grille with pin/cup retention system - Elastomer stick-on bumper feet (adds 3mm to height) - Acoustically transparent and FEA optimized grilles minimize diffraction - FEA-optimized cabinet and bracing eliminates resonances - Chamfered front baffle and flush-mounted drivers reduce edge diffraction and improved on-axis high frequency response - Wireless Streaming Options - DTS Play-Fi - Lossless 192kHz/24-bit via Critical Listening Mode over WiFi - Apple Airplay 2 for iPhone and iOS Devices, Chromecast for Android phones and Devices: CD Quality - Bluetooth 5.0 with AAC and aptX - Spotify Connect Input Specs: - HDMI audio input. Supports ARC and eARC - Left/Right RCA Input: Input Impedance: 20K - 3.5mm Aux Input: Input Impedance: 20K - Toslink Optical Input: S/PDIF receiver works at a wide range of sampling frequencies up to 96kHz - Bluetooth 5.0 with AAC and aptX - 6 front panel presets for one-touch access to music services and playlists Ethernet - USB service port also for powering wireless accessories: See SoundPath Wireless Audio Adapter
Output Specs: - Subwoofer Output: 2V MAX - Auto Detecting Low Pass Filter: Activates Low Pass Filter at 80Hz on the speakers when subwoofer detected - Ethernet
General Specifications: - 3.15” wide Front Panel OLED display: Displays Source, Artist Name, Song Title, Volume and Rich meta data from Wi-Fi and Bluetooth audio sources - Switch Mode Power Supply: Auto Switching 100 – 120V / 220 – 240V, 50/60Hz - Fuse: 15A/250V - Detachable Power Cord - IR Remote control and 2 AAA batteries included - 8 x Elastomer stick-on bumper feet included - Active-Passive Speaker Interconnect Cable: 3m / 10ft Included
