Powering this is a robust 325-watt RMS (820+ watts peak) Sledge Class D amplifier with discrete MOSFET output, ensuring effortless dynamics and ultra-low distortion. Its advanced 50MHz Analog Devices DSP allows for meticulous tuning, easily controlled via the groundbreaking SVS Subwoofer Control smartphone app (Bluetooth-enabled) for adjustments like volume, parametric EQ, phase, and room gain compensation from your listening position.
Housed in a rigid, internally braced MDF cabinet, the SB-1000 Pro provides precise, musical bass extending down to 20 Hz (±3 dB). With versatile RCA and speaker-level inputs, and a compact size (13 inches H×13.5 inches W×14.8 inches D), it's an ideal choice for high-performance bass in smaller to medium-sized rooms, blending seamlessly into any setup.
Features
Inspired Subwoofer Engineering for Uncompromised Performance.
The new SVS 1000 Pro Series features technology breakthroughs from the 16-Ultra Series, 4000 Series, 3000 Series, and 2000 Pro Series. This technology joins with exclusive 1000 Pro Series innovations to set a new standard for subwoofer performance value. More people than ever can now enjoy room-shaking bass below the threshold of human hearing with unerring accuracy and control.
Specifications
SUBWOOFER SPECS - Protective non-resonant extra-thick ABS fabric mesh grille - Iso-elastomer feet included - Extra heavy-duty, high current power cord 6' - Quick Start Guide - Unbalanced stereo input/output - Speaker Level Stereo Input - Auto/On and Trigger options through app, 3-12V AC/DC trigger - RoHS compliant, lead-free construction, world-wide safety certifications - Green 0.5-watt low standby power consumption - Dimensions (w/ grille): 13.5” (342mm) H X 13” (330mm) W X 14.76” (375mm) D - Dimensions (without grille): 13.5” (342mm) H X 13” (330mm) W X 13.9” (352mm) D - Shipped Dimensions: 17.4” (455mm) H 17.4” (442mm) W X 18.4” (471mm) D - Weight (unboxed): 26lbs (11.9kg) with Grille - Shipped Weight: 31.1lbs (15kg)
DRIVER SPECS Driver Specs: - All-new proprietary 12-inch long-throw driver with high-precision tuned overhung motor configuration. - 8.33lb (3.78kg) pound Woofer with 5.73lb (2.6kg) pounds motor - 13.3mm Xmax, 26.9mm Xmech precision aligned excursion - 1.5” diameter Voice Coil with high current 6-layer high-purity copper wire windings - Premium high-purity copper voice coil winding design minimizes distortion and power compression with maximum heat dissipation, linearity, and tuned magnetics for high excursion - Two-piece high grade oversized Y30 Ferrite magnet motor - High Temperature 3003-H18 aluminum former/bobbing - 6” composite cotton-poly extreme excursion linear spider - Dual 24-strand copper-alloy high-temperature leads - Proprietary injection molded gasket and NBR extreme-excursion surround - Lightweight treated Fiber Composite cone for enhanced sensitivity and transient response - Top plate assembly with low carbon 1010 steel for optimal magnetics - Oversized low carbon 1008 steel T-yoke with integrated pole piece extension for maximum cooling and electromagnetics - 12” premium powder coated basket with FEA optimized analysis for maximum rigidity, tensile strength, and energy transference - Oversized motor system for driving full excursion and industry best SPL, with pinpoint transient speed - Precision machining for motor and narrow tolerance suspension parts ensure flawless linearity at full range of excursion
AMPLIFIER SPECS - 325 watts RMS, 820+ watts peak power output Class D design - 50MHz Analog Devices Audio DSP, high resolution double precision 56bit filtering - Wide input voltage bandwidth compliant for consumer and pro audio up to 4V line level input. - High efficiency LLC resonant SMPS with 17A 650V MOSFET, resonant switching results in lower EMI and highest efficiency. - Cool-running Class D amplifier switching topology with massive 34A 120V MOSFET’s - SVS BLE control app for iOS and Android contains 3 complete name-able and customizable User presets, supports IOS (iphone5 or newer or Android (4.42 or newer), 3 PEQ's per preset, adjustable low pass, phase, polarity, room gain compensation, and control for best alignment with speakers. - Customer EQ and DSP limiter settings specifically for the 1000 Pro - Input impedance 16kohm (unbalance RCA) - Input impedance 1kohm (speaker level) - New Intelligent Feature control (IFC) user interface on the amplifier with bright blue 11 LED bar display and easy push-button controls.
