The hybrid tweeter combines ten 55 mm planar magnetostatic strips with a 35 mm soft dome, with crossover points at 800, 2,500 and 12,500 Hz. An 88 dB sensitivity and 6-ohm load make it undemanding, and the 40–400 W range leaves headroom for 110 dB peaks.
Technical Specifications
Crossover Principle3½-way
Tweeter10 × 55 mm planar magnetostatic tweeter, 1 x 35 mm soft dome
Woofer / Midrange2 x 7 inch
Frequency Range35 to 34,000
Crossover Frequency800 / 2,500 / 12,500
Sensitivity [dB]88
Nominal Impedance [Ohm]6
Maximum SPL [dB]110
Recommended Amplifier Power [W]40 - 400
Specifications: DALI. Distributed in the UAE by Cinefolks.
