Bass extends to 29 Hz and peaks reach 112 dB. The 4-ohm nominal load and 40–500 W recommendation both point towards a capable amplifier. Second-generation SMC joins EVO-K and Clarity Cone in the driver design.
Technical Specifications
Crossover Principle4-way
Tweeter10 × 55 mm planar magnetostatic tweeter, 1 x 35 mm soft dome
Woofer / Midrange2 x 8 inch / 1 x 6½ inch
Frequency Range29 to 34,000
Crossover Frequency400 / 3,100 / 12,500
Sensitivity [dB]88
Nominal Impedance [Ohm]4
Maximum SPL [dB]112
Recommended Amplifier Power [W]40 - 500
Specifications: DALI. Distributed in the UAE by Cinefolks.
