Two 6½-inch drivers operate in a 2½ + ½-way arrangement with a further crossover point at 800 Hz. Response is quoted from 49 Hz to 30 kHz and peaks at 110 dB, with 25–200 W recommended — a usefully wide window for matching.
Technical Specifications
Crossover Principle2½ + ½-way
Tweeter1 x 29 mm soft dome, 1 x 17 x 45 mm Planar
Woofer / Midrange2 x 6½ inch
Frequency Range49 to 30,000
Crossover Frequency800 / 2,200 / 14,000
Maximum SPL [dB]110
Recommended Amplifier Power [W]25 to 200
Specifications: DALI. Distributed in the UAE by Cinefolks.
