Bass reaches 49 Hz and the top end 25,000 Hz. The 4-ohm nominal load asks for a capable amplifier; 40 to 300 W is the stated range, with 90 dB sensitivity and up to 110 dB on tap.
Technical Specifications
Tweeter1 x 28 mm soft dome, 1 x 17 x 45 mm Planar
Woofer / Midrange2 × 7 inch wood fibre cone
Frequency Range49 to 25,000
Crossover Frequency1,000 / 2,800 / 15,000
Sensitivity [dB]90
Nominal Impedance [Ohm]4
Maximum SPL [dB]110
Recommended Amplifier Power [W]40 to 300
Specifications: DALI. Distributed in the UAE by Cinefolks.
