The hybrid tweeter pairs a 29 mm soft dome with a 17 x 45 mm planar unit crossing at 15,000 Hz, above a 3,000 Hz main crossover. Response runs 44 Hz to 25 kHz; weight is 18.5 kg.
Technical Specifications
Tweeter1 x 29 mm soft dome, 1 x 17 x 45 mm Planar
Frequency Range44 to 25,000
Crossover Frequency3,000 / 15,000
Sensitivity [dB]89
Nominal Impedance [Ohm]8
Maximum SPL [dB]112
Recommended Amplifier Power [W]40 to 350
Weight [kg/lb]18.5 / 40.8
Specifications: DALI. Distributed in the UAE by Cinefolks.
