Response spans 50 Hz to 26 kHz with peaks of 107 dB. Sensitivity sits at 87 dB and the nominal impedance is 4 ohms, so a well-specified amplifier within the 40–150 W range will get the best from it. SMC and Clarity Cone are used in the bass driver.
Technical Specifications
Crossover Principle2-way
Tweeter1 x 29 mm soft dome
Woofer / Midrange1 x 6½ inch
Frequency Range50 to 26,000
Crossover Frequency2,800
Sensitivity [dB]87
Nominal Impedance [Ohm]4
Maximum SPL [dB]107
Recommended Amplifier Power [W]40 to 150
Specifications: DALI. Distributed in the UAE by Cinefolks.
