Two 6½-inch drivers operate in a 2½ + ½-way configuration beneath a hybrid tweeter combining a 17 x 45 mm planar unit with a 29 mm soft dome, crossing at 800, 2,600 and 14,000 Hz. Bandwidth runs from 38 Hz to 34 kHz, peaking at 110 dB.
Technical Specifications
Crossover Principle2½ + ½-way
Tweeter17 x 45 mm Planar, 1 x 29 mm soft dome
Woofer / Midrange2 x 6½ inch
Frequency Range38 to 34,000
Crossover Frequency800 / 2,600 / 14,000
Sensitivity [dB]88.5
Nominal Impedance [Ohm]4
Maximum SPL [dB]110
Recommended Amplifier Power [W]40 to 200
Specifications: DALI. Distributed in the UAE by Cinefolks.
