The response covers 49 Hz to 34 kHz with peaks to 111 dB. Sensitivity is 89 dB into a 4-ohm load, with 40–200 W of amplification recommended.
Technical Specifications
Crossover Principle2 + ½-way
Tweeter17 x 45 mm Planar, 1 x 29 mm soft dome
Woofer / Midrange2 x 6½ inch
Frequency Range49 to 34,000
Crossover Frequency2,800 / 14,000
Sensitivity [dB]89
Nominal Impedance [Ohm]4
Maximum SPL [dB]111
Recommended Amplifier Power [W]40 to 200
Specifications: DALI. Distributed in the UAE by Cinefolks.
